Profile Powerhouse 35W/50W ballast testing data

Collapse
X

  • Filter
  • Time
  • Show
Clear All
new posts

  • Profile Powerhouse 35W/50W ballast testing data

    The Retrofit Source has created a ballast that can do both 35W and 50W, switching to the latter with the flip of a switch (or more accurately, the bridging of two contacts). This is a first for mainstream HID products and I was very excited to test it out!

    I compared the Powerhouse to a Hella Gen 3 that was modified with updated MOSFETs and on demand switching from 37W to 45W or 55W. Keep in mind that, yes, the Hella Gen 3 is at a higher wattage in both 37W and 55W modes so the numbers will be higher. Also the Gen 3 was custom made, so the wattage numbers may not be perfectly accurate and I have no control for the 55W portion. I plan to measure power draw of the ballast at 55W soon (if someone can suggest an easy way of doing this I'd be grateful!).

    For a 35W control, I used an Alpha HID 35W ballast that HK45 tested to output an actual 35 watts. Source: https://www.hidplanet.com/forums/for...bulbs-shootout

    So let's get to it! The photos are exposure and color balance locked. Lux meter results were peak readings taken after plenty of time for the ballast to warm up. The ballasts were powering well used CNLight H7 HID bulb in a halogen H7 Koito projector with a tuned clear lens. All photos and measurements were taken at 35 feet.

    Note: My photos of the Profile Powerhouse state that it runs at 55W. This is wrong, it runs at 50W. Please excuse the error.

    Hella Gen 3 at 37W: 379 lux







    Hella Gen 3 at 55W: 705 lux







    Profile Powerhouse at 35W: 302 lux







    Profile Powerhouse at 50W: 502 lux







    Alpha HID at 35W: 319 lux







    Comparison gifs:

    Hella Gen 3 37W vs Profile Powerhouse 35W exposure 1:



    Hella Gen 3 37W vs Profile Powerhouse 35W exposure 3:



    Alpha HID 35W vs Profile Powerhouse 35W exposure 1:



    Alpha HID 35W vs Profile Powerhouse 35W exposure 3:



    Hella Gen 3 55W vs Profile Powerhouse 50W exposure 1:



    Hella Gen 3 55W vs Profile Powerhouse 50W exposure 3:



    The output of the Profile Powerhouse in 35W mode is spot on at 35W, comparable to every other quality 35W ballast. At 50 the numbers seem to line up with what they should be, considering the upgraded MOSFETs in the 55W Hella Gen 3 (for better efficiency). The switch is instantaneous and the pigtail coming out of the ballast is a 9006 connector, perfect for hooking up to a high beam splitter for some extra wattage in high beam.

    Full review to come soon with corrected output photos, more photos of the ballast itself, and my thoughts on construction/functionality/quality!
    Last edited by Haloruler64; October 20, 2017, 04:31 AM.

    2000 Toyota MR2 Spyder
    2017 Lexus CT200h F Sport

  • #2
    There's been switchable ballasts before the Profiles; Auerswald had one in the early 2000s (I still have one operational unit), xevision (member D1S' company), and the "K9" brand I discovered back in January.

    You should be able to do the usual meter leads @ positive and negative to get voltage then meter leads in series @ positive to get amps, then multiply those values by each other to calculate power draw in watts (multiply that number by .85 for approximate wattage to the bulb). Or are there secondary power leads for the high-wattage circuit?

    PS wanna test one of those K9 ballasts? I could send you one if you agree to ship it back at your own expense
    Originally posted by HK45
    I don't even look to see what Eddie writes anymore. I'm too busy staring at his avatar.

    Comment


    • #3
      I was trying to say mainstream switchable ballast. Let me rephrase that.

      So my meter has to support high current to be put in series correct? I dunno how much the Powerhouse draws at startup, which is what concerns me, otherwise it'll be under 5A. No secondary wiring, the trigger is just two pins that need to be bridged.

      They're the 45W/60W correct? What are your thoughts on them? I remember you speaking about them. I wonder what shipping cost will be, I may be interested!

      2000 Toyota MR2 Spyder
      2017 Lexus CT200h F Sport

      Comment


      • #4
        Originally posted by Haloruler64 View Post
        So my meter has to support high current to be put in series correct? I dunno how much the Powerhouse draws at startup, which is what concerns me, otherwise it'll be under 5A.


        Most ballasts easily go over 5A @ startup. I tested some Fastbright F7s and had close to 8 amps draw at startup. I know Hellas are somewhat current hungry so they may peak at close to 10.

        They're the 45W/60W correct? What are your thoughts on them? I remember you speaking about them. I wonder what shipping cost will be, I may be interested!
        Yup they're claimed to be 45/60. Realistically they're probably like 35/50 to the bulb https://www.hidplanet.com/forums/for...ast-find/page3

        I planned to do light meter comparisons against some OEM and aftermarket 35w then some 50-55w; ultimately to be used on a MH1 7.0 retro (which I haven't even started on aaargh) since the bowls may peel from high-wattage usage,but home repair stuff and working 7-day work weeks have been taking my free time

        They're pretty compact ballasts , I can ship it safely in a small flat rate (reasonably priced) USPS box. PM your zip code.
        Originally posted by HK45
        I don't even look to see what Eddie writes anymore. I'm too busy staring at his avatar.

        Comment


        • #5
          Yeah I thought so. I'll see if my meter is beefy enough for that and I'll give it a shot!

          PM'd

          2000 Toyota MR2 Spyder
          2017 Lexus CT200h F Sport

          Comment


          • #6
            Most meters are fused for 10A. Otherwise you could fire them with a wire paralled across the meter leads to bypass the meter for startup
            The time you enjoy wasting, is not wasted time

            Comment


            • #7
              I'll check when I get home! I bought a meter that had a higher rating fuse than my regular one at some point.

              2000 Toyota MR2 Spyder
              2017 Lexus CT200h F Sport

              Comment


              • #8
                Nice,you can measure both amps and volts at the same time since you have two meters.
                Originally posted by HK45
                I don't even look to see what Eddie writes anymore. I'm too busy staring at his avatar.

                Comment


                • #9
                  WOOHOO!

                  2000 Toyota MR2 Spyder
                  2017 Lexus CT200h F Sport

                  Comment


                  • #10
                    Originally posted by Haloruler64 View Post
                    I'll check when I get home! I bought a meter that had a higher rating fuse than my regular one at some point.
                    Even the cheap hf meters have a 10A fuse, so if you're worried, pick one of those up
                    The time you enjoy wasting, is not wasted time

                    Comment


                    • #11
                      I bought a Craftsman, local and was like $8 at the time. AFAIK it's 10A as well. Probably the same meter.

                      2000 Toyota MR2 Spyder
                      2017 Lexus CT200h F Sport

                      Comment


                      • #12
                        I think i remember a pic of it, iirc, its slightly nicer than a cheap hf meter. That's what they give the free coupons for- so we can find unique ways to blow them up!
                        The time you enjoy wasting, is not wasted time

                        Comment


                        • #13
                          Nice pictures and comparisons! Last time I saw a switchable ballast available for sale (well only time) was retro-solutions long ago. Glad to see there is something decent finally! I just got rid of my dual-brightness ballasts a month or two back, so I was considering these new ones. How's the warmup time?

                          Comment


                          • #14
                            Originally posted by soundman98 View Post
                            I think i remember a pic of it, iirc, its slightly nicer than a cheap hf meter. That's what they give the free coupons for- so we can find unique ways to blow them up!
                            Yeah it's nicer. Really not bad.

                            Originally posted by gold94corolla View Post
                            Nice pictures and comparisons! Last time I saw a switchable ballast available for sale (well only time) was retro-solutions long ago. Glad to see there is something decent finally! I just got rid of my dual-brightness ballasts a month or two back, so I was considering these new ones. How's the warmup time?
                            Thanks! What happened to your dual brightness ballasts?

                            The warm up time isn't slow, but it's not quick. It's quicker than expected, knowing the standard Morimoto's warm up time.I can take a video if you'd like.

                            2000 Toyota MR2 Spyder
                            2017 Lexus CT200h F Sport

                            Comment


                            • #15
                              I have the freebie coopiní HF meter; the leads are horrible,one actually began melting while testing for amperage...wasnít surprised since the actual wire in the leads are like the thickness of human hair LOL

                              Originally posted by Haloruler64 View Post
                              The warm up time isn't slow, but it's not quick. It's quicker than expected, knowing the standard Morimoto's warm up time.I can take a video if you'd like.
                              I could probably throw in a F5 ballast with the K9 (no additional shipping cost since itís flat rate) if you want to compare warmup time, and also a good light meter and power draw comparison to the other ballastsí high-wattage mode :-)
                              Originally posted by HK45
                              I don't even look to see what Eddie writes anymore. I'm too busy staring at his avatar.

                              Comment
